PA 60 2nd

Dieser Regler war die zweite Version des PA 60 und hatte ein Auslassventil aus Gummi

This reg was the second version of the PA 60 and featured an outlet from rubber





Hersteller / Manufacturer

Dräger

Model

PA 60

gebaut / built

1958-1959

max. Luftlieferleistung / max.air delivery

no Information by now

Stages

2





Stage 1

Upstream

Balanced ?

no

Type

membrangesteuert / Diaphragm activated

Mitteldruck / IP

keiner / none

HP-Port

no





Stage 2

upstream

Type

no

LP-Port

no





Gehäuse/Housing

Metal, chromed

Membrane Ø  / Diaphragm Ø

13 cm

max Druck / Pressure

200 bar

Anschluss/Fitting

DIN

Luftauslass/ Exhaust

Gummidichtung/rubber mushroom

Anschluss Gehäuse Ø/ Fitting Housing Ø

no Information by now

Mundstück/Mouthpiece

T-Mundstück / T-Mouthpiece

Anschluss Mundstück Ø /Fitting Mouthpiece Ø

no Information by now

Gesehen wo/Seen on

my collection, manual

Special notice



Techn. drawing

no

Service manual

no

PA-60 2nd

PA-60 2nd

Outside PA 60 2nd

Outside PA 60 2nd

Label PA 60 2nd

Label PA 60 2nd

Inside PA 60 2nd

Inside PA 60 2nd

Backside PA 60 2nd

Backside PA 60 2nd

Mouthpiece PA 60 2nd

Mouthpiece PA 60 2nd
