Essgee MK II

Der Essgee MK II war ein Essgee MK I ohne erste Stufe mit Oberflächenversorgung

The Essgee MK II was in fact an Essgee MK I without first stage, surface supplied

Hersteller / Manufacturer

Siebe Gorman (license La Spirotechnique)

Name

MK II

gebaut / built



max. Luftlieferleistung / max.air delivery

no Information by now

Stages

1





Stage 1

no

Balanced?

no

Type

no

Mitteldruck / IP

unknown

HP-Port

no





Stage 2

downstream

Type

no

LP-Port

Hookah





Gehäuse/Housing

Metal

Membrane Ø  / Diaphragm Ø

11,5 cm

max Druck / Pressure

unknown

Anschluss/Fitting

Hookah

Luftauslass/ Air outtake

Entenschnabelventil / duckbill





Anschluss Gehäuse Ø/ Fitting Housing Ø

no Information by now

Mundstück/Mouthpiece

T-Mundstück / T-Mouthpiece

Anschluss Mundstück Ø /Fitting Mouthpiece Ø

no Information by now

Gesehen wo/Seen on



Special notice

late models had a metal plate to protect the duckbill.

Techn. drawing

no

Service manual

no

Siebe-Gorman-MK-II-alt

Siebe-Gorman-MK-II-alt

Label-Siebe-Gorman-MK-II-al

Label-Siebe-Gorman-MK-II-al

Backside-+-Harness-Siebe-Go

Backside-+-Harness-Siebe-Go

Inside-Siebe-Gorman-MK-II-a

Inside-Siebe-Gorman-MK-II-a

Mouthpiece-SG-MK-II-old

Mouthpiece-SG-MK-II-old

Siebe-Gorman-MK-II

Siebe-Gorman-MK-II

Label-Siebe-Gorman-MK-II

Label-Siebe-Gorman-MK-II

Back-side-Siebe-Gorman-MK-I

Back-side-Siebe-Gorman-MK-I

Inside-Siebe-Gorman-MK-II

Inside-Siebe-Gorman-MK-II

Mouthpiece-Siebe-Gorman-MK-

Mouthpiece-Siebe-Gorman-MK-
